Technical Parameter

1. Maximum working pressure: 3000 PSI (206 bar) @ 100℃; F(37℃);

2. Working temperature range: -20℃; F (-28℃) to 450℃; F (232℃).


Test

1. Each valve undergoes nitrogen testing at a test pressure of 1000 PSI (69 bar) and a maximum leakage rate of 0.1 std cm³/ s;

2. Static pressure shell pressure test can be conducted at 1.5 times the maximum working pressure.
