Product Features

1. Compact structure;

2. The opening pressure can be adjusted externally;

3. The available steel wire locking proportional unloading valve for calibrating the opening pressure effectively maintains the set pressure;

4. Each valve undergoes testing before leaving the factory.

Technical Data

1. Maximum working pressure: 6000PSI (414bar);

2. Opening pressure: 225PSI to 6000PSI (15.5 bar to 414 bar);

3. Diameter: 3.6mm;

4. Multiple springs correspond to different pressures.
